Thiết bị lưu trữ Qnap VS-8148Pro+

  • Thiết bị lưu trữ Qnap VS-8148Pro+
  • Thiết bị lưu trữ Qnap VS-8148Pro+
  • Thiết bị lưu trữ Qnap VS-8148Pro+
  • Thiết bị lưu trữ Qnap VS-8148Pro+
  • Thiết bị lưu trữ Qnap VS-8148Pro+
  • Thiết bị lưu trữ Qnap VS-8148Pro+
  • Thiết bị lưu trữ Qnap VS-8148Pro+
  • Thiết bị lưu trữ Qnap VS-8148Pro+
  • thumbnail Thiết bị lưu trữ Qnap VS-8148Pro+
  • Thiết bị lưu trữ Qnap VS-8148Pro+
  • Thiết bị lưu trữ Qnap VS-8148Pro+
  • Thiết bị lưu trữ Qnap VS-8148Pro+

Giá bán: 144,736,760₫

  • Processor : Intel Core™ i3-2120 processor
  • HDD Capacity : 8 x 3.5-inch SATA 6Gb/s, SATA 3Gb/s hard drive Note: The system is shipped without HDD.
  • Hard Drive Tray : 8 x hot-swappable and lockable tray
  • LAN Port : 2 x Gigabit RJ-45 Ethernet port
  • LED Indicators : Status, LAN, USB, hard drive LEDs
  • Hãng sản xuất : Qnap
  • Xuất xứ : Chính hãng
  • Bảo hành : 12 tháng
  • Trạng thái : Còn hàng
  • VAT : Đã bao gồm VAT

F5 CORP - Cung cấp Dịch vụ Bán hàng toàn quốc uy tín

Hà Nội: 560 Trường Chinh, Đống Đa, Hà Nội

Đà Nẵng: 36 Kiều Oánh Mậu, Hoà Minh, Liên Chiểu, Đà Nẵng

HCM: 248 Hoàng Hoa Thám, P.12, Q.Tân Bình, TP.HCM

The Qnap VS-8148 Pro+ VioStor NVR is a 48-channel network video recorder for IP cameras. It supports high quality real-time video and audio monitoring, up to 10-megapixel recording, and playback of multiple IP cameras.

It features 8 hot-swappable and lockable trays, each for a separately-sold 3TB RAID drive. In total, the 8148 supports up to 24TB of physical storage and is capable of H.264, MxPEG, MPEG-4, and M-JPEG recording from up to 48 IP cameras. A Linux-based standalone NVR, the 8148 sets up in 6 easy steps by Internet Explorer without extra software or even a PC required but rather via an HDMI or VGA connection to a local display.

The recorder is compatible with more than 1,000 IP cameras and video servers from popular brands including AXIS, ACTi, A-MTK, Arecont Vision, AVTECH, Brickcom, Canon, Cisco, CNB, DIGITUS, D-Link, EDIMAX, ELMO, EtroVision, GANZ, Hikvision, iPUX, IPX, IQeye, LevelOne, Linksys, Messoa, MOBOTIX, NAKAYO, Panasonic BB/BL/i-Pro, SANYO, SHANY, Sony, Samsung, TOA, TOSHIBA, TRENDnet, Videosec, VIOSECURE, VIVOTEK, Y-CAM, and Yokogawa.

Complete Recording Functions

Recording
High Quality H.264, MPEG-4, M-JPEG, and MxPEG recording
All-In-One Recording Functions
Continuous, manual, schedule recording
Alarm recording (by multiple events), and alarm recording schedule
Pre-alarm and post-alarm recording
Audio recording
Megapixel Recording
Supports up to 10-megapixel recording from various IP cameras
Generic IP Cameras Support
Provides an interface for users to enter the JPEG CGI command of their IP cameras so to retrieve video and audio data from IP cameras
Real-Time Digital Watermarking
Supports real-time digital watermarking to protect videos and snapshots from unauthorized modification. The Watermark Proof utility is provided to verify whether or not videos and snapshots are original

PC-Less Network Surveillance by HD HDMI or VGA Local Display

Diversified Modes for Local Monitoring
1, 4, 6, 8, 9, 10, or 12-channel display mode
Sequential display mode
High Resolution Local Display
Provides an HDMI interface which can be connected to an HDMI monitor or TV for monitoring in full HD 1920 x 1080 resolution
Convenient Control of PTZ and Speed Dome Cameras
PTZ (Pan/Tilt/Zoom) cameras can be adjusted directly and the preset positions of the IP cameras can be viewed on the local display interface of the VioStor NVR
Digital Zoom
Digital zoom (in/out) of the video image is supported on the monitoring and playback interfaces of the NVR
On-Screen Event Alert
When an event occurs, an alert icon will be shown instantly on a local monitoring page. The alert details can be viewed by clicking the alert icon
Video Search
Provides convenient video search by date and time on the local playback interface
Local Video Playback on HDMI Monitor or TV
Supports video playback directly on an HDMI monitor or TV
Quick System Setup
The VioStor NVR can be set up in simple steps on a local display interface

Network Surveillance by Web-Based Interface (Internet Explorer)

Multi-Server Monitoring
Connect to one VioStor NVR and monitor up to 128 channels from other VioStor NVR servers over LAN or WAN by an IE browser
Diversified Remote Monitoring Modes
1, 4, 6, 8, 9, 10, 12, 16, 20, 25, 36, or 42-channel and sequential display mode
Exclusive picture-in-picture mode
Multi-display mode
Smart Control of PTZ & Speed Dome Cameras
PTZ (Pan/Tilt/Zoom) cameras can be adjusted directly by the web user interface of the VioStor NVR
Preset Position Control and Auto Cruising
The preset positions of an IP camera can be viewed by clicking the corresponding number buttons on the monitoring page. The time interval can also be configured on the PTZ cameras for periodic monitoring
Instant Event Notification
When alarm recording is enabled and an event occurs, an alarm icon is shown instantly on the monitoring page. The alert details can be viewed by clicking the icon
Digital Zoom
Digital zoom (in/out) of the video image is supported on the monitoring and playback interfaces
Dynamic E-Map
The VioStor NVR provides an E-map function for users to upload digital maps and indicate the locations of the IP cameras of a monitoring location or region

Remote Video Playback

Multi-View Playback
Use the multi-view playback feature to divide a video equally into multiple sessions for playback in a multi-view window, or play the videos of multiple IP cameras in the multi-view window simultaneously
Video Search by Date and Time, Timeline, Event, Intelligent Video Analytics (IVA)
The VioStor NVR supports quick video search by date and time, timeline, event, and intelligent video analytics (IVA), which includes motion detection, foreign object, missing object, out of focus, and camera occlusion

Event Management

Advanced Event Management
The VioStor NVR supports various event handling options for different kinds of events
Events: Motion detection, alarm input, connection failure, recording failure, and user-defined event
Actions: Video recording, email alert, SMS alert, buzzer, PTZ camera control, alarm output, and user-defined action
Real-Time SMS and Email Alert
Configure the SMTP server and SMSC server settings on the NVR in order to receive instant system warning or error messages by email and/or SMS

Convenient Backup Solution

Scheduled Remote Replication
The VioStor NVR supports scheduled remote replication for secure data backup to a remote QNAP NAS on a local network
One Touch Auto Video Backup
Configure the one-touch auto video backup button on the front of the NVR to copy the data from the NVR to an external storage device when the button is pressed

Security Control

Authority Management
Create multiple users on the VioStor NVR and assign them to different user groups (administrator, system manager, or user) with different rights of monitoring, playback, PTZ control, and audio monitoring
Auto Logoff
The VioStor NVR supports automatic user logoff from idling configuration pages. The administrator can set the timeout period to log users off when at the end of idling time
Host Access Control
Specify the host or IP connections to be allowed and denied access to the NVR
On-Line User List
View the record of users currently logged on and previously logged on
Detailed Event Logs
The VioStor NVR provides detailed event logs of system warning, hard disk error, network disconnection, UPS status, and access to the networking services of the NVR and video recordings

High Reliability and Smart Features

Advanced RAID with Hot-Swap Design
The VioStor NVR supports RAID 0, 1, 5, 6, 5+hot spare, 6+hot spare, single, and JBOD disk configurations. Its hot-swap design allows a failed drive of a disk volume, RAID 1 or above, to be replaced by hot swapping without turning off the server
Online RAID Capacity Expansion
The storage capacity of a RAID configuration can be expanded by replacing the hard drives with larger ones. All the data will be kept and seamlessly moved to the newly installed hard drives. There is no need to turn off the server during the process
Online RAID Level Migration
Upgrade the disk configuration to higher RAID level with the data retained without turning off the server
S.M.A.R.T. & Advanced HDD Health Scanning (HHS)
S.M.A.R.T. (Self-Monitoring Analysis and Reporting Technology) helps monitor the hard disk drives' status. The VioStor NVR supports HHS (HDD Health Scan) for disk checking and bad blocks scanning
Automatic System Startup After Power Recovery
The VioStor NVR supports automatic system startup after a power recovery
UPS Support for 24/7 Service
The VioStor NVR supports APC, CyberPower, MGE, and YEC UPS devices to provide continuous services 24/7 against unexpected power outage
DOM Architecture with Embedded Fail-Safe Dual OS for Enhanced Reliability
All the OS and applications of the VioStor NVR are embedded on the DOM. The VioStor NVR allows system booting without accessing the physical disk sectors which prevents unsuccessful system startups caused by bad blocks or file errors on the hard drives. Two operating systems are built on the DOM for system booting alternatively upon every system startup. When one fails, the other one takes over for system startup and the failed OS is recoverable from the other healthy OS

Network Services

Dual Gigabit LAN Ports
Failover: allows the VioStor NVR to sustain the failure of one network port to provide continuous services
Load Balancing: provides bandwidth aggregation to boost the file transfer speed (works with managed Ethernet switch with 802.3ad configured)
Multi-IP Settings: Two IP settings can be configured on the NVR to allow network access from two different subnets
Built-In DDNS Service
The VioStor NVR supports dynamic DNS (DDNS) for convenient access to the system via a domain name instead of a lengthy IP address
Built-In NTP Server
Allows the connected IP cameras to synchronize their date and time settings with the NVR
Convenient Data Access
The video data on the VioStor NVR can be accessed by the following protocols with proper access rights:
SMB/CIFS (Windows)
HTTP (Web file management)
FTP

Easy Configuration and Management

Web-Based User Interface
All system configurations, monitoring, and playback features of the NVR can be managed by the web-based interface
VS-8148 Pro+ Specifications
Processor Intel Core™ i3-2120 processor
HDD Capacity 8 x 3.5-inch SATA 6Gb/s, SATA 3Gb/s hard drive
Note: The system is shipped without HDD.
Hard Drive Tray 8 x hot-swappable and lockable tray
LAN Port 2 x Gigabit RJ-45 Ethernet port
LED Indicators Status, LAN, USB, hard drive LEDs
USB 2 x USB 3.0 (front:1; back:1)
4 x USB 2.0 (rear:4)
Front: for USB storage device (One touch auto video backup)
Rear: for UPS device
Buttons Power button, one touch auto video backup button, reset button
LCD Panel Mono-LCD display with backlight
Enter button, Select button for configuration
Alarm Buzzer System warning
Form Factor Tower
Dimensions 217.5(H) x 327(W) x 321.2(D) mm
8.56(H) x 12.8(W) x 12.65(D) inch
Weight Net weight: 8.39 kg (18.48 lb)
Gross weight: 13.98 kg (30.79 lb)
Temperature 0~40˚C / 32~104˚F
Relative Humidity 0~90% R.H.
Power Supply Input: 100-240V AC, 50/60Hz,
Output: 350W
Power Consumption (W) 101W Write/Read (with 8 x 1TB HDD installed)
Secure Design K-Lock security slot for theft prevention
Video Output 1x HDMI
1x VGA
Fan 2 x 12cm smart cooling fan
Certification CE, FCC, VCCI, BSMI, C-Tick
Package Contents
  • VS-8148 Pro+
  • CD-ROM
  • Ethernet cable x 2
  • Power cord
  • Flat head screw x 32 (for 3.5" HDD)
  • Flat head screw x 32 (for 2.5" HDD)
  • Quick Installation Guide
