Thiết bị lưu trữ Qnap VS-6116Pro+

Giá bán: 67,065,460₫

Processor : Dual-core Intel processor
DRAM : 4GB RAM
HDD Capacity : 6 x 3.5-inch SATA 6Gb/s, SATA 3Gb/s hard drive Note: The system is shipped without HDD.
Hard Drive Tray : 6 x hot-swappable and lockable tray
LAN Port : 2 x Gigabit RJ-45 Ethernet port

Hãng sản xuất : Qnap
Xuất xứ : Chính hãng
Bảo hành : 12 tháng
Trạng thái : Còn hàng
VAT : Đã bao gồm VAT

Mua ngay Giao tận nơi

F5 CORP - Cung cấp Dịch vụ Bán hàng toàn quốc uy tín

Hà Nội: 560 Trường Chinh, Đống Đa, Hà Nội

Đà Nẵng: 36 Kiều Oánh Mậu, Hoà Minh, Liên Chiểu, Đà Nẵng

HCM: 248 Hoàng Hoa Thám, P.12, Q.Tân Bình, TP.HCM

Powered by the Intel dual-core processor and 4GB of memory, the QNAP Systems Inc. VS-6116 Pro+ 16-Channel VioStor Tower NVR delivers high performance at a throughput rate of 330 Mbps to ensure stable recording and smooth playback of multiple megapixel cameras. The 6-bay, VS-6116 Pro+ is designed for the SMB segment with the features of robust performance, solid reliability, and high-definition local display.

The VS-6116 Pro+ has a storage capacity of up to 24TB, with 4TB on each hard drive respectively, to accommodate high-quality H.264, MPEG-4, M-JPEG, and MxPEG recording videos. The server-grade mainboard, Sanyo Denki system fan, and heat pipe with fanless design assure solid reliability for maximized system uptime. Moreover, the VS-6116 Pro+ supports local display via an HDMI cable, with up to 180 fps Full HD 1080p local display by hardware decoding.

All-In-One Recording Functions: Supports H.264, MPEG-4, M-JPEG, and MxPEG recordings
Continuous, manual, and scheduled recording
Alarm recording (by multiple events), alarm recording schedule
Pre-alarm and post-alarm recording
Audio recording
Auto snapshot ¹

Megapixel Recordings: Supports megapixel recordings (up to 10 Mp) from various IP cameras

Real-Time Digital Watermarking: Protects the videos and snapshots from unauthorized modifications
Watermark proof utility is provided to verify whether or not the videos and snapshots are original

Network Surveillance: Supports different video modes like 1, 4, 6, 8, 9, 10, 12, or 16-channel, dual-display, and sequential display modes
Provides an HDMI port which can be connected to an HDMI monitor or a TV for monitoring in the full HD (1920 x 1080) resolution
Convenient control of PTZ & speed dome cameras allows you to adjust the PTZ cameras as well as view preset positions of the IP cameras on the local display interface
Digital zoom allows you to zoom in and out of the video image, allowing for flexible monitoring and playback
On-screen event alert icons are immediately displayed on the local monitoring page in case any event occurs
Video search by date and time is allowed on the local playback interface
Supports direct local video playback on HDMI monitors or TVs
Features a quick system setup on the local display interface
Cross-platform support lets you view live content and playback recording files on your Windows- or Mac-based PC by using the QNAP Surveillance Client software
With cross-browser compatibility on the Windows PC, you can also use Google Chrome, Microsoft Internet Explorer, or Mozilla Firefox for surveillance
Can be connected to monitor up to 128 channels from other VioStor NVR servers over the LAN or WAN via an IE browser
The PTZ (pan/tilt/zoom) cameras can be directly adjusted by the web user interface of the device
Preset position control and auto-cruising allow you to configure PTZ cameras to cruise according to the preset positions along the time interval for each preset position
When the alarm recording is enabled and an event occurs, an alarm icon will be shown instantly on the monitoring page. The alert details can be viewed by clicking the icon
The E-map function lets you upload digital maps and indicate the locations of the IP cameras of a monitoring location or region
Mobile Surveillance by VMobile enables you to remotely view live content and playback recordings on your portable mobile devices over Wi-Fi, 3G, or 4G
The fisheye dewarping function, available on the web and local display interface for specific fisheye cameras and specific cameras with panomorph lens, assists in doing practical surveillance management, allowing administrators to view the monitored area clearly ²

Remote Video Playback: Using multi-view playback, you can divide a video into multiple sessions equally for playback in a multi-view window and play videos of multiple IP cameras in the multi-view window simultaneously
Quick data search can be performed by date & time, timeline, event, and intelligent video analytics (IVA) such as motion detection, missing object, foreign object, out of focus, camera occlusion, etc

Advanced Event Management: Allows you to mange several events like motion detection, alarm input, connection failure, recording failure, and other user-defined events
Enables you to handle several actions like video recording, email alert, SMS alert, buzzer, PTZ camera control, alarm output, and other user-defined actions
Real-time SMS and email alert are provided in case of system error or emergencies to the administrator immediately

Backup Solution: The Scheduled Remote Replication feature enables you to copy the recording data of the local VioStor to a remote QNAP NAS (Network Attached Storage) on the local network
Using the One-Touch Auto-video Backup solution, you can immediately copy the recording data to a compatible USB device

Hardware Design: Powered by an Intel CPU and DDRIII memory card, the NVR delivers high performance for surveillance applications
Built-in Japanese Sanyo Denki System Fan
The CPU thermal solution uses a fanless design to provide good performance, quiet operation, and enhanced reliability
Linux-based NVR is less vulnerable to virus attacks
Using the Touch-N-Go PC-less installation feature, you can complete the first-time system installation, including hard disk initialization and RAID configuration of the NVR via the LCD panel without using any PC
Supports up to 24TB of physical storage capacity (6 x 4TB hard drives) for recording a large amount of video data over a long period of time

Security Control: The Authority Management feature lets you create different user groups, i.e., an administrator, a system manager, and a user who can be assigned different rights for having access to monitoring, playback, PTZ control, and audio monitoring
The Auto Log-Off feature allows you to set the timeout period to log off the users when the idling time is over
With Host Access Control, you can specify the host or IP connections that are to be allowed and denied to access the NVR
An online user list allows you to view the record of users currently logged on and those who had previously logged on to the NVR
Detailed event logs offer logs of system warning, hard disk error, network disconnection, UPS status, users' networking services, and recordings access record

High Reliability and Smart Features: Advanced RAID with hot-swap design offers single disk, RAID 0, RAID 1, RAID 5, RAID 5+hot spare, and JBOD disk configurations due to which a failed drive of a disk volume (RAID 1 or above) can be replaced through hot swapping without turning off the server
Online RAID capacity expansion and online RAID level migration allow you to upgrade the disk configuration to a higher RAID level, retaining the existing data and without turning off the server
S.M.A.R.T. (Self-Monitoring Analysis and Reporting Technology) is used to monitor hard disk status
Supports Advanced HHS (HDD Health Scanning) for disk checking and bad blocks scanning
Includes automatic system startup after a power recovery
DOM Architecture with Embedded Fail-Safe Dual OS for enhanced reliability ensures that 2 operating systems are installed on the DOM, so as to boot the system alternatively
Supports APC, CyberPower, MGE, and YEC UPS devices to provide continuous services 24/7 against unexpected power outages
Video server support

Network Services: The built-in DDNS support allows you to create a unique registered domain name from a DDNS service provider for use with the NVR
The built-in NTP server uses the NTP (Network Time Protocol) to synchronize the date and time of the network cameras with that of the NVR
You can conveniently access the recording data on the NVR through the Network Neighborhood (SMB / CIFS), Web File Management (HTTP), or FTP server

Easy Configuration and Management: Can be set up in 6 simple steps via the local display or web-based interface (Internet Explorer)
All the system configurations, monitoring, and playback features can be managed by the web-based interface
With the intelligent software utility finder, you can quickly search IP cameras and configure system settings on the local network

VS-6116 Pro+ Specifications
Processor	Dual-core Intel processor
DRAM	4GB RAM
HDD Capacity	6 x 3.5-inch SATA 6Gb/s, SATA 3Gb/s hard drive Note: The system is shipped without HDD.
Hard Drive Tray	6 x hot-swappable and lockable tray
LAN Port	2 x Gigabit RJ-45 Ethernet port
LED Indicators	Status, LAN, USB, HDD1-6
USB	2 x USB 3.0 port (Back: 2) 5 x USB 2.0 port (Front: 1; Back: 4) Support pen drive, USB mouse, USB keyboard, USB sound card, and USB UPS etc.
Buttons	Power button, One-touch-auto-video-backup button, Reset button
LCD Panel	Mono-LCD display with backlight Enter button, Select button for configuration
Alarm Buzzer	System warning
Audio	Audio In/Out for local display
Form Factor	Tower
Dimensions	185 (H) x 260 (W) x 235 (D) mm 7.28 (H) x 10.24 (W) x 9.25 (D) inch
Weight	Net weight: 5.7 kg (12.56 lbs) Gross weight: 7.0 kg (15.43 lbs)
Temperature	0~40˚C / 32~104˚F
Relative Humidity	5~95% RH non-condensing, wet bulb: 27˚C.
Power Supply	Input: 100-240V AC, 50/60Hz, Output: 250W
Power Consumption (W)	In Operation: 91W (with 6 x 2TB HDD installed)
Secure Design	K-Lock security slot for theft prevention
Video Output	1 x HDMI Suggested video output resolution: 1920 x 1080 (Full HD)
Fan	2 x quiet cooling fan (92 mm, 12V DC)
Certification	CE, FCC, VCCI, BSMI
Package Contents	VS-6116 Pro+ CD-ROM (User manual & utility inclusive) Ethernet cable x 2 Power cord Flat head screw x 28 (for 3.5" HDD) Flat head screw x 28 (for 2.5" HDD) Quick Installation Guide Hard Disk Lock
