Giá bán: 211,053,220₫

  • Processor : Quad Core Intel Core™ i5 3.7GHz Processor
  • DRAM : 8GB DDR3 RAM
  • HDD Capacity : 12 x 3.5” SATA 6Gb/s, SATA 3Gb/s hard drive Note: The system is shipped without HDD.
  • Hard Drive Tray : 12 x hot-swappable and lockable tray
  • LAN Port : 4 x Gigabit RJ-45 Ethernet port
  • Hãng sản xuất : Qnap
  • Xuất xứ : Chính hãng
  • Bảo hành : 12 tháng
  • Trạng thái : Còn hàng
  • VAT : Đã bao gồm VAT

F5 CORP - Cung cấp Dịch vụ Bán hàng toàn quốc uy tín

Hà Nội: 560 Trường Chinh, Đống Đa, Hà Nội

Đà Nẵng: 36 Kiều Oánh Mậu, Hoà Minh, Liên Chiểu, Đà Nẵng

HCM: 248 Hoàng Hoa Thám, P.12, Q.Tân Bình, TP.HCM

The QNAP VS-12140U-RP-PRO+ VioStor Network Video Recorder is the high-end 2U chassis network surveillance server that supports high quality real-time video/audio monitoring, megapixel recording (up to 10 Mp), and playback of multiple IP cameras. The VioStor VS-12140U-RP-PRO+ NVR (Network Video Recorder) can simultaneously handle inputs from up to 40 megapixel cameras.

Featuring a powerful Quad-core Intel Core i5 processor and 8GB of DDR3 memory, this enterprise-grade NVR delivers high performance with a throughput of 450 Mb/s for recording and smooth playback of multiple megapixel cameras. Moreover, the HDMI output and hardware decoder of this NVR provide the ability to deliver up to 300 fps full HD local display.

In addition, when installing the 4TB hard drives, the VioStor VS-12140U-RP-PRO+ NVR supports up to 48TB storage capacity, which makes it proficient for continuous recording of high-resolution video. This Linux-based recorder saves power, is less vulnerable to virus attacks, and enables quick and easy deployment of multiple NVRs. It is designed with the user in mind, offering simple and intuitive setup in 6 steps. Coupled with powerful performance and stability, this solution is tailor-made for enterprise surveillance needs.

The NVR can be set up in 6 simple steps via the local display or Web-based interface (Internet Explorer). All the system configurations, monitoring, and playback features of the NVR can be managed by the Web-based interface.

Recording Functions
  • High quality H.264, MPEG-4, M-JPEG, and MxPEG recordings (depending on the camera models)
  • Continuous/manual/scheduled recording
  • Alarm recording (by multiple events), alarm recording schedule
  • Pre- and post-alarm recording
  • Audio recording
  • Auto snapshots
1
General
  • Megapixel Recordings: The VioStor NVR supports megapixel recordings (up to 10-megapixel) from various IP cameras
  • High Resolution Local Display: The VioStor NVR features an HDMI port that can be used to connect an HDMI monitor or a TV for monitoring and direct video playback in full HD (1920 x 1080) resolution
  • Convenient Control of PTZ and Speed Dome Cameras: PTZ (Pan/Tilt/Zoom) cameras can be adjusted directly and preset positions of IP cameras can be viewed on the local display interface of the VioStor NVR
  • Video Search: The VioStor NVR supports convenient video search by date and time on the local playback interface. Digital zoom (in/out) of the video images is supported on the monitoring and playback interfaces of the NVR
  • Quick System Setup: The VioStor NVR can be set up in simple steps on the local display interface
  • Cross-Platform Support: Use QNAP Surveillance Client for Windows and Mac for viewing live videos and playing back recorded ones on the VioStor NVR
  • Cross-Browser Compatibility: On a Windows PC, you can also use Google Chrome, Microsoft Internet Explorer, or Mozilla Firefox to enjoy our surveillance features
  • Multi-Server Monitoring: Connect to a VioStor NVR and monitor up to 128 channels from other VioStor NVR servers over the LAN or WAN via the IE browser
  • Smart Control of PTZ & Speed Dome Cameras: PTZ (Pan/Tilt/Zoom) cameras can be directly adjusted by the Web user interface of the VioStor NVR
  • Dynamic E-Map: The VioStor NVR provides the E-Map function for users to upload the digital maps and indicate the locations of the IP cameras of a monitoring location or region
  • Multi-View Playback: Use the multi-view playback feature to divide a video equally into multiple sessions for playing back in a multi-view window, or simultaneously play the videos recorded by multiple IP cameras in the multi-view window
  • Video Search by Date and Time, Timeline, Event, IVA (Intelligent Video Analytics): This NVR supports quick video search by date and time, timeline, event, and IVA (Intelligent Video Analytics), which includes motion detection, foreign object, missing object, out of focus, and camera occlusion
  • Real-Time SMS and Email Alerts: Configure the SMTP server and SMSC server settings on the NVR in order to receive instant system warnings or error messages by email and/or SMS
  • Scheduled Remote Replication: The VioStor NVR supports scheduled remote replication for securing data backup to a remote QNAP NAS on the local network
  • Intel CPU and DDRIII Memory: Powered by the Intel CPU and DDRIII memory, this NVR delivers high performance for surveillance applications
Additional Features
  • High Storage Capacity for Long-term Recordings: The NVR supports up to 48TB of physical storage capacity (4TB hard drive x 12) for recording a large amount of video data over a long period of time
  • Host Access Control: Specify the host or IP connections to be allowed or denied to access the NVR
  • Online User List: View the record of users currently logged on and previously logged on to the NVR
  • Detailed Event Logs: The VioStor NVR provides detailed event logs of system warnings, hard disk errors, network disconnections, UPS status, and access to the networking services of the NVR and video recordings
  • Automatic System Startup after Power Recovery: The NVR supports automatic system startup after a power recovery
  • UPS Support for 24/7 Service: The VioStor NVR supports APC, CyberPower, MGE, and YEC UPS devices to provide continuous services 24/7 against unexpected power outages
  • Built-In DDNS Service: The NVR supports DDNS (Dynamic DNS) for convenient access to the system by a domain name instead of a lengthy IP address
  • Built-In NTP Server: This feature allows the connected IP cameras to synchronize their date and time settings with the NVR
  • Convenient Data Access: The video data on the VioStor NVR can be accessed via the SMB/CIFS (Windows), HTTP (Web file management), and FTP protocols with proper access rights
  • Smart Search of IP Cameras for Quick Settings: QNAP provides an intelligent software utility, finder, to search for IP cameras and configure the system settings on the local network quickly
  • Fisheye Dewarping: Available on the web and local display interface for specific fisheye cameras and specific cameras with panomorph lens, assists in doing practical surveillance management, allowing the administrators to view the monitoring area in a clearer shape
  • 360° Panomorph video support for specific IP camera with panomorph lens on remote monitoring/playback and local display interface
  • Authority Management: Create multiple users on the VioStor NVR and assign them to different user groups (administrator, system manager, or user) with different rights for doing monitoring, playback, PTZ control, and audio monitoring
  • Auto Logoff: The VioStor NVR supports automatic user logoff from idling configuration pages. The administrator can set the timeout period to log off the users when the idling time has been reached
  • Online RAID Level Migration: Upgrade the disk configuration to a higher RAID level with the data retained without turning off the server
  • Certifications: CE, FCC, VCCI, BSMI, and LVD
2
Multi-Stream Support
  • Administrators now can flexibly define multiple video streams (supported by specific camera models) according to bandwidth resources and number of live-view channels
  • Adjustable video stream setting helps improve the displaying quality of live-view and well manage the bandwidth resources based on different usage requirements
Smart Recording
  • Automatically selects video streams from IP cameras for different recording scenarios
  • Effectively avoids the constant storage consumption at all time, but achieves greater storage efficiency and boost recording quality when alarm events happen
  • In normal situation, video recording maintains at lower quality resolution
  • During an alarm event, video recording switches to high quality resolution to capture more details
Real-Time Digital Watermarking
  • Supports real-time digital watermarking to protect the videos and snapshots from unauthorized modifications
  • Watermark Proof utility is provided to verify whether or not the videos and snapshots are original
Network Surveillance with Full HD 1080P Local Display
  • Diversified Modes for Local Monitoring: 1, 4, 6, 8, 9, 10, 12, or 16-channel display modes, sequential display mode
  • Diversified Remote Monitoring Modes: 1, 4, 6, 8, 9, 10, 12, 16, 20, 25, 36, 42, 64-channel, and sequential display modes, dual-display mode
Preset Position Control and Auto Cruising
  • Preset positions of an IP camera can be viewed by clicking the corresponding number buttons on the monitoring page
  • Time interval can also be configured on the PTZ cameras to perform periodic monitoring
Instant Event Notification
  • When the alarm recording is enabled and an event occurs, an alarm icon will be shown instantly on the monitoring page
  • Alert details can be viewed by clicking the icon
Advanced Event Management
  • VioStor NVR supports various event handling options for different kinds of events
  • Events: Motion detection, alarm input, connection failure, recording failure, and user-defined event
  • Actions: Video recording, email alert, SMS alert, buzzer, PTZ camera control, alarm output, and user-defined action
On-Screen Event Alert
  • When an event occurs, an alert icon will be shown instantly on the local monitoring page
  • Alert details can be viewed by clicking the alert icon
Storage Expansion
  • VioStor NVR provides surveillance storage expansion solution, which enables users to leverage the Turbo NAS storage capacity
  • By installing the StorageExpansion QPKG in the Turbo NAS, administrators can connect the VioStor NVR with the Turbo NAS to flexibly enlarge the total surveillance storage
Mobile Surveillance by VMobile
  • Use the VMobile network surveillance application on Android phones, Android tablets, iPhones, iPads, or iPod Touch to easily access video management functions
  • The account on the NVR can be used to connect to an unlimited number of NVRs and IP cameras by VMobile through Wi-Fi, 3G, or 4G networks
Advanced RAID with Hot-Swap Design
  • The VioStor NVR supports RAID 0, 1, 5, 6, 5+hot spare, single, 6+hot spare, and JBOD disk configurations
  • Allows a failed drive of a disk volume (RAID 1 or above) to be replaced by hot swapping without turning off the server
Online RAID Capacity Expansion
  • The storage capacity of a RAID configuration can be expanded by replacing the hard drives with larger ones
  • All the data will be kept and seamlessly moved to the newly installed hard drives
  • There is no need to turn off the server during the process
S.M.A.R.T. and Advanced HDD Health Scanning (HHS)
  • Helps monitor the hard disk drives status
  • Supports HHS (HDD Health Scan) for disk checking and bad block scanning
DOM Architecture with Embedded Fail-Safe Dual OS for Enhanced Reliability
VS-12140U-RP Pro+ Specifications
Processor Quad Core Intel Core™ i5 3.7GHz Processor
DRAM 8GB DDR3 RAM
HDD Capacity 12 x 3.5” SATA 6Gb/s, SATA 3Gb/s hard drive
Note: The system is shipped without HDD.
Hard Drive Tray 12 x hot-swappable and lockable tray
LAN Port 4 x Gigabit RJ-45 Ethernet port
LED Indicators Status, 10 GbE, LAN, eSATA, hard drives
*10 GbE (reserved), eSATA (reserved)
USB 2 x USB 3.0 ( back:2)
4 x USB 2.0 ( back:4)
Exporting recording file in playback by USB3.0 ports only.
Buttons Power button, reset button
Alarm Buzzer System warning
Form Factor 2U, Rack mountable
Dimensions 88(H) x 439(W) x 520(D) mm
3.46(H) x 17.28(W) x 20.47(D) inch
Weight Net weight: 15.88 kg (35.01 lb)
Gross weight: 25.60 kg (56.44 lb)
Temperature 0~40˚C / 32~104˚F
Relative Humidity 5~95% RH non-condensing, wet bulb: 27˚C.
Power Supply Input: 100-240V AC, 50/60Hz,
Output: 600W
Power Consumption (W) 167W Write/Read (with 12 x 2TB HDD installed)
Expansion Slot 2 (reserved for network and storage expansion)
Video Output 1 x HDMI
1 x VGA
Fan 3 x 6cm smart cooling fan
Certification CE, FCC, VCCI, BSMI, C-Tick
Package Contents
  • VS-12140U-RP Pro+
  • CD-ROM
  • Ethernet cable x 4
  • Power cord x 2
  • Flat head screw x 48 (for 3.5" HDD)
  • Flat head screw x 48 (for 2.5" HDD)
  • Quick Installation Guide
  • 2U Rail Kit: SP-X79U-RAIL-KIT
