Cisco MGBLH1 Gigabit Ethernet LH Mini-GBIC SFP Transceiver

Cisco MGBLH1 Gigabit Ethernet LH Mini-GBIC SFP Transceiver

4,814,000₫



Specifications
Media Single-mode fiber (SMF)
Application 1000BASE-LH
Connector type Duplex LC
Wavelength typical (Tx) 1310 nm
Wavelength range (Rx) 1310 nm
Performance
Maximum distance up to 40 km
Average output power -4 dBm to 0 dBm
Receiver sensitivity -25 dBm (typ)
-3 dBm
Environmental
Dimensions W x H x D 13.4 x 8.5 x 56.5 mm (0.53 x 0.33 x 2.22 in.)
Unit weight 0.018 kg (0.63 oz. )
Power 1W (max)
Operating temperature 32º to 158ºF (0º to 70ºC)
Storage temperature -40º to 185ºF (-40º to 85ºC)
Operating humidity 10% to 85% noncondensing
Storage humidity 5% to 90% noncondensing
Standards
Compliance
FCC Part 15 Class B

EN55022 Class B (CISPR 22B)

VCCI Class B
Safety
FDA 21 CFR 1040.10 and 1040.11

EN60950, EN (IEC) 60825-1,2



Module quang GLC-LH-SM SFP Singlemode, 1.25Gbps

Module quang GLC-LH-SM SFP Singlemode, 1.25Gbps

5,700,000₫

Thông tin sản phẩm
Hãng sản xuất Cisco
Thông số kỹ thuật
Phụ kiện dành cho Catalyst 2960&3560&3750
Kiểu khe cắm SFP
Tốc độ truyền dữ liệu 1000 Mbps
Chuẩn giao tiếp BASE-LX/LH



Thêm sản phẩm để so sánh
